CheckPoint Meter for MAP: Portable Precision in O2 and CO2 Analysis
Portable gas analyzer for quality control in modified atmosphere packaging (MAP), the CheckPoint meter represents the most advanced solution for accurately and efficiently monitoring oxygen (O2) and carbon dioxide (CO2) levels in packaged products. Its portable and robust design makes it an essential tool for production lines requiring high reliability and operational agility.
Equipped with a new long-life ceramic sensor, it offers consistent and accurate results without the need for daily calibration. Thanks to its WiFi connectivity, it enables direct and seamless data management, optimizing quality control and traceability. The 3.5" color touchscreen, along with its intuitive interface, facilitates use in any industrial environment, enhancing transparency throughout the MAP packaging process.
Key Features
- New solid-state ceramic O2 sensor.
- O2 or combined O2/CO2 measurements.
- Integrated sample flow control.
- Data collection and transfer via WiFi.
- Optimized data processing for higher speed.
- 3.5" high-resolution color touchscreen for easy reading.
- Compatible with low-cost standard needles.
- Optional stainless steel needles available.
- Storage capacity for 1 million records.
- Sensor warranty of 2 to 3 years.
- Includes protective cover.
- Multilingual interface.
- Graphical statistics display.
- For more information about technical specifications, operation, CheckPoint models and more, SEE TECHNICAL DATASHEET.
Advantages
- No PC software required.
- Easy to use in production environments.
- Optimizes quality control in MAP systems.
- Increases operational efficiency.
- Improves process transparency.
- Helps protect brand image.
- Sets a new standard in portable analyzers.
- Reduced maintenance costs.
- No daily calibration needed (20.9%).
Technical specifications:
| Available configurations |
Solid-state ceramic O2 sensor |
O2 & CO2 (infrared sensor) |
| Sample volume |
5 ml |
5 ml |
| Measurement time |
9 seconds |
9 seconds |
| Measurement range |
0-85% |
0-100% (on CO2 sensor) |
| Resolution |
0.1% oxygen |
0.1% oxygen and carbon dioxide |
| Sensor accuracy at 1% O2 and 20% CO2 |
Better than ± 0.1% ± 2% of reading |
Better than ± 0.1% oxygen and
Better than ± 2% carbon dioxide |
| Warm-up time |
5 seconds |
5 seconds |
| Dimensions and weight |
75 x 100 x 175 mm (H x W x D)
0.7 Kg |
- |
| Power supply |
Battery, max. recharge time 5 hours, ready for 2,000 measurements |
- |
| Options |
Standard consumables kit (1 sampling kit, 1000 septa, 10 needles (Ø 0.8) & 10 filters), steel needles |
- |
| Connections |
WiFi (WPA, WPA 2, WPA enterprise) |
- |
| Calibration and review |
12 months |
- |
| Expected sensor lifespan |
O2 > 3 years
CO2 > 5 years |
- |
| Operating temperature |
0 - 40 °C |
- |
| Compliance |
RoHS, China RoHS, CE |
- |
| Data packages |
Extended memory – up to 1 million measurements |
- |
| What's in the box? |
100 septa, 10 needles (Ø 0.8), 10 filters, charger with multi-plug adapter (US, EU, AU, UK) |
- |
