PORTABLE CLEANING CENTRAL FOR 2 PRODUCTS WITH SATELLITE
Otros
Web Code: 9060 Catalogue code: 70411
3,730.35 € (VAT not included)
4,513.72 € (21% VAT included)
Portable stainless-steel cleaning central equipped with a satellite for 2 foaming/disinfecting chemical products. Includes wheels, dosing system, reducers, and professional accessories.
Long term delivery.
3,730.35 € (VAT not included)
Return and refund policies
2% discount on online orders

2% web discount

on online orders

Quality products

QUALITY PRODUCTS

+ 5,000 references in stock

Reysan Whatsapp: Ask us what you want

+0034 603 721 702

Ask us what you want

BIG QUANTITIES: Special offers

BIG QUANTITIES

Special offers

Portable Cleaning Station for Two Products with Stainless Steel Satellite

The portable cleaning station for 2 products with satellite is designed for professional cleaning, foaming, and disinfection applications in industrial environments. Its stainless steel structure ensures durability, hygiene, and ease of maintenance, allowing operation with foaming and disinfectant chemical products through a precise and safe dosing system.

Main features

  • Solid and durable stainless steel construction, suitable for continuous use in demanding environments.
  • Two large wheels and two swivel wheels with brakes ensuring stability at the workplace.
  • Ergonomic handle for easy movement.
  • Integrated space for chemical product containers.
  • Compatible with seal train mounting.
  • Built-in bumpers that protect against damage to walls or machines.
  • Satellite for two foaming/disinfectant chemical products.
  • Dosing through high-precision nozzles.
  • Includes air reducer with pressure gauge and liquid separator.
  • Reliable manual control mechanism with foam (chemical agents) and water (rinse) functions.
  • Equipped with stainless steel ball valve with female quick coupling.
  • Chemical agent, water, and air suction inlets protected with stainless steel check valves.
  • Dryer and pressure gauge protected by stainless steel housing.
  • Hygienic structure with no need for side clearance for maintenance.
  • Satellite installation possible on wall or on a mobile point.
  • Inclined roof and satellite base (15°) preventing sediment accumulation.
  • Easy access to the injector for quick maintenance.
  • Four lower holes for hanging lances.
  • Rear panel with four mounting holes.
  • Base designed to hang lances and suction tube.
  • Satellite equipped with automatic shut-off valve for compressed air.

The cleaning station includes:

Technical data

Specification Value
Weight 80 kg
Maximum dimensions 76 x 123 x 119 cm
Maximum load 250 kg
Diameter and spacing of mounting holes 7 mm; 2 × 205 × 190 mm
Dosing range 0.3–8 %
Minimum water supply flow rate 30 l/min
Water inlet 1/2” F
Water outlet (female quick coupling) 1/2”
Water pressure 18–40 bar
Air outlet 6 mm
Minimum air flow rate 150 l/min
Air supply pressure 5–8 bar
Units per package 1
