ELECTRONIC ATURIDER TEQ002

Characteristics ELECTRONIC ATURIDER TEQ002

• Eliminates micro-hemorrhages and organ damage.
• It facilitates the work and diminishes the manpower.
• Provides a quiet meating cycle, with relaxed and easily hooked animals.
• Lower PH values and higher quality.
• It allows recording the details of the fundamental electrical parameters for each stunned animal.
• Hermetic IP55 containment box in painted metal.
• Dimensions: 40 x 60 x 20 cm.
• Microprocessor that memorizes the stunning parameters.
• Portable memory with capacity for thousands of data.
• Connection to the computer without wires for data visualization and printing.
• Screen for the visualization of the stunning current.
• Configuration by push button of the animal species that must be stunned.
• Memorization of the split change by pushbutton.
• Acoustic and luminous indicator to warn about the current level range.
• Electrical panel with insulation and safety transformer to CEI 14-6 standard, secondary insulation class mass greater than 3KW.
• Protection against overload and short circuit in the clamp and in the power supply of the transformer.
• Equipped with electrical adjustment of the output voltage displayed on the screen.
• Equipped with a device that measures the impedance of the animal and prevents operation if the programmed current is not reached.
• Socket 16A with 2 poles IP65 hermetically to IEC standard for connection pincers.
• Ver ficha técnica.
