Emergency Eyewash and Shower in Galvanized Steel for Industrial and Chemical Protection
The emergency eyewash and shower is designed to provide immediate first aid in case of contact with chemical, radioactive substances or fire, protecting both the worker’s eyes and body. Made of galvanized steel, it combines strength, durability, and a functional design that allows mechanical washing and removal of harmful substances via lever, pedal, and pull handle.
Key Features
- Structure in galvanized steel for strength and durability in industrial and chemical environments.
- Shower and eyewash activated by pull handle, lever, or pedal for immediate response.
- Complies with UNE EN 15154-1-2 standard for safety showers and eyewash stations connected to the water supply.
- Recommended installation:
- Lowest point of the shower head: between 210 and 230 cm.
- Highest point of the eyewash bowl: between 80 and 115 cm.
- Exclusive supply with potable water to ensure safe eye and body washing.
- Designed for first aid in case of chemical, radioactive or fire splashes in industrial and chemical plants.
- Important precautions to consider:
- Have a prevention technician evaluate possible chemical reactions of water with products present in the environment.
- The water should mainly provide a mechanical effect of removing harmful substances from eyes and body.
- Do not prolong washing longer than necessary in low temperature conditions to avoid thermal shock; provide blankets for the affected person.
- The installation of the device must be carried out by qualified personnel according to current regulations.
- Recommended for areas where fire, chemical, or radioactive splashes may occur and immediate first aid is required.
- Ideal for environments where the atmosphere is not particularly saline or corrosive.
Connection Sizes:
| Component |
Size |
| Shower head |
10’’ (diameter) |
| Bowl |
11 ½’’ (diameter) |
| Eyewash valve |
3/8’’ |
| Water supply connection |
½’’ |
| Water drainage connection |
1 ¼’’ |
Pressure Ranges:
| Parameter |
Value |
| Minimum working pressure |
0.2 MPa* |
| Maximum working pressure |
0.8 MPa* |
| Maximum static pressure |
0.9 MPa* |
*MPa = Megapascal = N/mm² = 10 bar
Materials:
| Component |
Material |
| Shower head |
ABS |
| Shower valve |
Chrome-plated steel |
| Shower pull handle |
Chrome-plated steel |
| Connection pipe |
Galvanized steel |
| Bowl |
ABS |
| Eyewash pull handle |
Chrome-plated steel |
| Pedal |
Iron |
| Chain |
Iron |
| Base |
Iron |
